30 The Enpac Ex
13. Press 2 on the data collector’s numeric key pad to start the transfer.
14. In the WinSerDL dialog box, click Start Download.
A progress bar displays in the dialog box indicating the progress of the
transfer. A message also displays at the bottom of the Enpac Ex screen.
This transfer may take as long as 20 minutes.
15. When the message "Transfer complete" displays on the Enpac screen,
close the WinSerDL dialog box and disconnect the Enpac Ex from the
computer.
16. Press the ON/OFF key for one second to power off the Enpac Ex.
17. Press the ON/OFF key to power on the Enpac Ex. Allow at least thirty
seconds for the unit to reconfigure and activate the LCD display. The
Enpac Ex powers up under Windows CE and starts the operating
system that was loaded in the unit.
IMPORTANT
This must be done 5 to 10 seconds of pressing 2 on the
unit or the Enpac Ex may timeout.
IMPORTANT
It will be necessary to re-enter the date and time in the
Enpac Ex. You may also want to review other instrument
settings, for example memory and trigger. Refer to Setting
the Date, Time, and Date Format on page 22.
TIP
To confirm that the correct version was loaded, tap the
About button on the Main Screen. The Firmware Version
should match the operating system file just loaded.
