Publication GMSI00-UM001A-EN-E - February 2005

Loading and Unloading 69

To manually initialize the data collector any time

You must have the Enpac Ex connected to the computer. You can also use the
Enpac Ex to initialize memory.

1. Select Tools > Load/Unload.

2. Click the D.C. Functions button in the Load/Unload dialog box. The

Data Collector Functions dialog box appears.

3. Click the Initialize Data Collector button. A progress bar appears

providing a status of the initialization.

4. When initialization is complete, click Close.

Loading Inspection Codes

Emonitor and the Enpac Ex support loading inspection codes with a list. The
Enpac Ex stores inspection codes with a loaded list. You can only load
inspection codes with a list.

1. Select Tools>Load/Unload.

2. Click the Load Options button in the Load/Unload dialog box. The

Load Options dialog box appears.

Check to load

inspection

codes
