Publication GMSI00-UM001A-EN-E - February 2005
Loading and Unloading 75
the correct measurement definition. Refer to Collecting Off Route Data using
a Pre-Defined Measurement on page 90
.
If Emonitor can match the unscheduled data to an item in the Hierarchy Tree
and a location, then it stores the unscheduled data in measurement definitions
under that location. If Emonitor cannot match the data with an existing
measurement definition, then it creates a new measurement definition and
stores the data there.
If Emonitor cannot match an item in the Hierarchy Tree and a location, it
stores the data in the unscheduled destination, set with Tools > Set
Unscheduled Dest.
Emonitor tries to match the collection specification for the measurement
definition. The rules for matching a collection specification are as follows.
If Emonitor cannot match the collection specification, it creates a new
collection specification using a code. The new collection specification name
has the form XXXXLMSWNNEp, where:
TIP
To have Emonitor put all unscheduled measurements in
one location, open the Load/Unload dialog box and click
the Unload Options button. Clear the Unscheduled
location smart mode check box.
Table 4.1 Rules for Matching a Collection Specification
All types Magnitude Spectrum Time Waveform
All these measurement
parameters in the
collection specification
must match: Transducer
Averaging type
Number of Averages
Percent Overlap
Order Normalization Transducer
Averaging type
Number of Averages
Percent Overlap
Order Normalization
Fmax (or Frequency
Span)
Number of lines Transducer
Averaging type
Number of Averages
Percent Overlap
Order Normalization
Fmax (or Frequency
Span)
Number of lines
Signal detection Transducer
Averaging type
Number of Averages
Percent Overlap
Order Normalization
Signal detection
XXXX maximum frequency
L number of lines
M transducer type
S signal detection
W window type
NN number of averages
E average type
p phase measurement flag
