Page 107
101
Publication GMSI00-UM100A-EN-E - February 2005
Appendix
A
Specifications
Appendix A lists the technical specifications for the Enpac Ex.
Enpac Ex Technical Specifications
Product Feature
Specification
Enclosure
Size
Weight
Case
Display
Connectors
186mm x 93mm (narrowest point)
186mm x 134mm (widest point)
850g (1.6 lbs)
Material: Faradex AX110 (ABS with
stainless steel fibers)
Hand strap fixing either side of unit.
LCD, Backlit Monochrome, Touchscreen
1/4 VGA (240 x 320) 58mm x 77mm
viewable
Signal Input: 4 Pin Fischer 102 type
Power in/Battery Charge: 2 Pin Fischer 102
type
Trigger Input: 3 Pin Fischer 102 type
System
Operating System
Processors
OS Storage (for WinCE & Apps)
Internal Flash Disk (Data & Applications)
Internal RAM
PC Comms
LED Indicators
Microsoft Windows® CE
MIPS R4000, DSP Motorola 56307
16 Mb FLASH
8 Mb FLASH
8 Mb SDRAM
RS-232 (9 way D type plug)
IrDA (not currently supported)
Red, Amber and Green
Battery
Type
Capacity
Power
Gauge
Rechargeable
Rechargeable NiMH pack
1800 mAHr
8 hours minimum, in use
Battery capacity indicator
Internal via power adapter
