76 Loading and Unloading
The parameters of the fields in the collection specification name are explained
in the Emonitor online help.
Automatically Printing Reports after Unloading
You can select reports to automatically send to a printer after unloading data
from the Enpac Ex. The reports contain information on the list of
measurements unloaded. See the Emonitor online help for more information
on printing reports and plots.
1. Select Tools > Load/Unload. The Load/Unload dialog box appears.
2. Make sure the correct data collector appears in the Set up collector
button. If not, see Set Up the Data Collector for Communication on
page 66.
3. Click the Unload Options button. The Unload Options dialog box
appears.
4. Select the Print reports check box and then select the reports you want
Emonitor to run automatically after unloading data.
5. Click OK.
