72 Loading and Unloading
1. Select Tools > Load/Unload. The Load/Unload dialog box appears.
2. Select the desired list or lists. See Selecting the List(s) on page 71.
3. Click the Load button in the Load/Unload dialog box. The following
series of events occurs.
– Emonitor builds the load file and shows a progress bar. If you wish
to stop the process, click Abort.
– Emonitor loads the file into the data collector and a second progress
bar appears.
4. When finished, click Close.
Displaying the Data Collector Driver Version Number
The data collector driver is the software that allows Emonitor to communicate
with the Enpac Ex. You can display the data collector driver version number in
Emonitor.
1. Select Tools > Load/Unload. The Load/Unload dialog box appears.
2. Make sure the correct data collector appears in the Set Up Collector
button. If not, see Connecting the Data Collector and Computer on
page 66.
3. Click the D.C. Function button. The Data Collector Function dialog
box appears.
4. Click the About data collector drive button. This displays the driver
version number.
TIP
For details on displaying the data collector operating
system version number in the Enpac Ex, see Displaying the
Operating System Version Number on page 24.
