Publication GMSI00-UM001A-EN-E - February 2005
The Enpac Ex 17
Assembling the Strap The strap can be fitted to either the left or right side of the Enpac Ex.
1. Feed the ends of the strap through the top and bottom corner pillars as
shown in the illustration below.
2. Loop the ends of the strap through the buckles and adjust the tightness
to suit.
System Modes The Enpac Ex has two modes:
• CE Operation - This is the default mode. In this mode, the Enpac Ex
application runs automatically under the Windows CE Operating
System.
• Bootloader Configuration - The bootloader screen can be initiated
following a hardware reset by holding down the LEFT and RIGHT
ARROW keys when powering on the Enpac Ex, or when the power has
been initially applied.
In this mode, you can re-initialize the Windows CE, or load an operating
system to the Enpac Ex through a serial connection.
IMPORTANT
The Enpac Ex does not use a CF Card at this time.
