Rockwell Automation 441-PEN25 Enpac Ex Data Collector User Manual
Page 108
Publication GMSI00-UM100A-EN-E - February 2005
102 Specifications
Environmental
Sealing
Drop Test
Operating Temperature Range
Storage Temperature Range
Humidity
Certification
IP65 (Dust and Water Proof)
1 Meter (to Mil-Std 810)
-10°C to +50°C (14°F to 122°F)
-20°C to +60°C (-4°F to +140°F)
0% to 80 Relative Humidity
ATEX
II 1G EEx ia IIC T4
Signal Measurement
Input Signal Types
Signal Inputs
Measurement Parameters
Measurement Types
Machine Identification
Accelerometers
Velocity transducers
Displacement Probes
Photo-optical Pickups
DC Inputs
Manual Entry
ICP™ (20V @ 3.5mA)
AC Signal
DC Signal
Tachometer (Trigger input-photo
optical/etc.)
Acceleration
Velocity
Displacement
gSE
ESP
Temperature
Phase
Voltage
User specified
Overall
Spectrum
Time Waveform
Phase
Order Normalized
Spectral Band Alarm
Plant
Train
Machine and point ID
Point description
Units
Alarm Levels
Previous Measurements,
Alarm Types
Enpac Ex Technical Specifications
Product Feature
Specification
