Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 211

Publication 2364F-5.01– October 2003
Programming Parameters
D-67
Table D.1 Alphabetical Parameter Listing
Parameter Name
Number
1 Phase Err Delay
148
1 Phase Threshld
147
14 Bit A/D Chan 2
38
14 Bit A/D Chan 3
39
14 Bit A/D Chan 4
40
14 Bit A/D Chan 5
41
14 Bit A/D Chan 6
42
14 Bit A/D Chan 7
43
14 Bit A/D Chan 8
44
14 Bit A/D Chan 9
45
Abs Junct Temp
86
ADC0 Input
36
ADC1 Input
37
Apparent Power
153
AutoRef Tracking
130
Aux Id Command
101
Aux Iq Command
89
Aux Iq Limit
88
Aux Relay Hyst
192
Aux Relay Ind
189
Aux Relay Mask
190
Aux Relay Select
191
Aux Volt Cmd
122
Bus Error
142
Bus Feedback
141
Bus Hi Setting
29
Bus Low Setting
28
Bus Prefil Fbk
140
Bus Rate Ref
126
Bus Ref Auto
129
Bus Reference
128
Bus V Tolerance
30
Bus Volt Cal
144
Bus Volt Cmd
207
Bus Volt Damping
206
Bus Volt In Sel
139
+Bus Volt to Gnd
145
-Bus Volt to Gnd
146
Bus Voltage BW
205
Clear Fault Mask
226
Clr Fault Owner
232
CrossCouple Gain
64
Current Loop Ki
68
Current Loop Kp
69
DAC1 Cutoff Freq
52
DAC1 Gain
51
DAC1 Indirect
49
DAC1 Offset
50
DAC1 Output
47
DAC2 Cutoff Freq
56
DAC2 Gain
55
DAC2 Indirect
53
DAC2 Offset
54
DAC2 Output
48
DC Bus Current
107
Disable Owner
230
DSP Ave DC Bus
61
DSP Bandwidth
198
DSP Damping
199
DSP DC Bus
60
DSP Status
62
Enable Mask
225
Enable Owner
231
Ext Capacitance
203
Fault Status 1
174
Fault Status 2
177
Fault Status 3
180
Fault Status 4
183
Fault/Warn Mask1
176
Fault/Warn Mask2
179
Fault/Warn Mask3
182
Fault/Warn Mask4
185
Feedback Select
219
Filtered Iq Ref
95
Flt Report Mask 1
175
Flt Report Mask 2
178
Flt Report Mask 3
181
Flt Report Mask 4
184
Frame Catalog #
4
Heatsink Temp
87
Host Command
32
Host Mode
35
Host Status 1
33
Host Status 2
34
Iac Total
108
Id Command
102
Id Feedback
106
Id Mode Select
103
Id Neg Limit
105
Id Pos Limit
104
Parameter Name
Number
Id Ref Scaled
66
Id Reference
93
Ide Current Lim
67
Int Capacitance
204
Int Charge Rate
201
Iq Change Rate
200
Iq Command
94
Iq Fbk Offset
99
Iq Feedback
100
Iq Integ Output
120
Iq Ki Gain
119
Iq Kp Gain
118
Iq Mode Select
90
Iq Neg Limit
92
Iq Pos Limit
91
Iq Ref Scaled
65
Iq Reference
96
Iqe Fbk DSP
71
It Fldbk Cur Lim
83
kVA Hours
156
kVAR Hours
157
kW Hours
155
Language Sel
3
Leadlag Freq, Kn
138
Leadlag Freq, Wn
137
Line Hi Setting
27
Line Inductance
12
Line Low Setting
26
Line Voltage
14
Line Voltage Cal
15
Linear PI Out
84
Master Status
20
Max Bus Ref
125
Meter Reset Day
164
Meter Reset Hours
161
Meter Reset Minute
162
Meter Reset Month
163
Meter Reset Year
165
Min Bus Ref
124
MVA Hours
159
MVAR Hours
160
MW Hours
158
Net Id Cmd, DSP
70
Net Iq Neg Limit
98
Net Iq Pos Limit
97
Parameter Name
Number
