Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 156

Publication 2364F-5.01– October 2003
D-12
Programming Parameters
43
A/D Converter 7 Input
[14 Bit A/D Chan 7]
This parameter receives an analog-to-digital
sample from the heatsink thermoswitches to
provide the value for P87 (Heatsink Temperature).
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-8191 (-10V signal)
Maximum Value
8191 (+10V signal)
Related Parameters
P187
The listing for P36 shows a quick reference
chart for converting the display value into
the analog input voltage.
44
A/D Converter 8 Input
[14 Bit A/D Chan 8]
This parameter receives an analog-to-digital
sample (+15V).
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-8191 (-10V signal)
Maximum Value
8191 (+10V signal)
The listing for P36 shows a quick reference chart
for converting the display value into
the analog input voltage.
45
A/D Converter 9 Input
[14 Bit A/D Chan 9]
This parameter receives an analog-to-digital
sample (-15V).
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-8191 (-10V signal)
Maximum Value
8191 (+10V signal)
The listing for P36 shows a quick reference chart
for converting the display value into
the analog input voltage.
46
P46 is for internal use only.
