Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 161

Publication 2364F-5.01– October 2003
Programming Parameters
D-17
65
Iq Reference to DPS
[Iq Ref Scaled]
This parameter indicates the scaled active current
reference (Iq) to be used by P96
(Iq Current Reference).
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
65535
66
Id Reference to DPS
[Id Ref Scaled]
This parameter indicates the scaled reactive
current reference (Id) to be used by P93
(Id Reference).
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
65535
Related Parameters
P93
67
Ide Current Limit to DPS
[Ide Current Lim]
This parameter indicates the reactive current limit
value to be by P104 (Id Positive Current Limit).
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
65535
Related Parameters
P104
68
Current Loop Ki
[Current Loop Ki]
This parameter indicates the current loop integral
gain (Ki). This provides an intermediate value
which is to be used by other parameters.
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
89
Minimum Value
0
Maximum Value
65535
69
Current Loop Kp
[Current Loop Kp]
This parameter indicates the current loop
proportional gain (Kp). This provides an
intermediate value to be used by other
parameters.
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
2392
Minimum Value
0
Maximum Value
65535
70
Id Feedback DSP
[Net Id Cmd, DSP]
This parameter indicates the DSP command for
the Id feedback converter.
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 5120/100
Factory Default
0
Minimum Value
0
Maximum Value
65535
71
Iq Feedback DSP
[Iqe Fbk DSP]
This parameter indicates the DSP command for
the Iq feedback converter.
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
65535
72-82
P72-P82 are for internal use only.
