Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) - Manual (Page 155)

Publication 2364F-5.01– October 2003
Programming Parameters D-11
38
A/D Converter 2 Input
[14 Bit A/D Chan 2]
This parameter receives an analog-to-digital
sample from the DC bus to provide the value for
the Scaled Bus Feedback (P143).
Parameter Type Source (Read Only)
Display Units None
Drive Units Display Units * 1
Factory Default 0
Minimum Value -8191 (-10V signal)
Maximum Value 8191 (+10V signal)
Related Parameters P139, P143
This parameter is sent to P143 when
Host Channel is selected in the Bus Voltage
Input Select (P139 = 2).
The listing for P36 shows a quick reference
chart for converting the display value into
the analog input voltage.
39
A/D Converter 3 Input
[14 Bit A/D Chan 3]
This parameter receives an analog-to-digital
sample from the negative DC bus and PE to
provide the value for P146 (Negative DC Bus To
Ground Voltage).
Parameter Type Source (Read Only)
Display Units None
Drive Units Display Units * 1
Factory Default 0
Minimum Value -8191 (-10V signal)
Maximum Value 8191 (+10V signal)
Related Parameters P146
The listing for P36 shows a quick reference
chart for converting the display value into
the analog input voltage.
40
A/D Converter 4 Input
[14 Bit A/D Chan 4]
This parameter receives an analog-to-digital
sample from the positive DC bus and PE to
provide the value for P145 (Positive DC Bus To
Ground Voltage).
Parameter Type Source (Read Only)
Display Units None
Drive Units Display Units * 1
Factory Default 0
Minimum Value -8191 (-10V signal)
Maximum Value 8191 (+10V signal)
Related Parameters P145
The listing for P36 shows a quick reference
chart for converting the display value into
the analog input voltage.
41
A/D Converter 5 Input
[14 Bit A/D Chan 5]
This parameter receives an analog-to-digital
sample from the AC line to provide the value for
P14 (Measured AC Line Voltage).
The listing for P36 shows a quick reference chart
for converting the display value into the analog
input voltage.
Parameter Type Source (Read Only)
Display Units None
Drive Units Display Units * 1
Factory Default 0
Minimum Value -8191 (-10V signal)
Maximum Value 8191 (+10V signal)
Related Parameters P14
42
A/D Converter 6 Input
[14 Bit A/D Chan 6]
This parameter receives an analog-to-digital
sample from the AC line (composite line voltage)
to provide the value for P14 (Measured AC Line
Voltage).
Parameter Type Source (Read Only)
Display Units None
Drive Units Display Units * 1
Factory Default 0
Minimum Value -8191 (-10V signal)
Maximum Value 8191 (+10V signal)
Related Parameters P14
The listing for P36 shows a quick reference
chart for converting the display value into
the analog input voltage.
