Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 152

Publication 2364F-5.01– October 2003
D-8
Programming Parameters
32
Host Command Word
[Host Command]
This parameter commands the processor to
perform the function(s) indicated by each fault bit
which is set to 1.
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0000 0000 0000 0000
Minimum Value
0000 0000 0000 0000
Maximum Value
0000 1111 1111 1111
Related Parameters
P33, P34, P35
For example, to command the processor to clear
faults, you would enter the command
word, 0000 0000 0000 0001.
Bit
Description
0
Clr Faults
Sends a command to clear faults in the RGU
1
Enable Cmd
Sends a command to Enable RGU control
2
Meter Reset
Sends a command to reset the watt-hour meter
3
Save Command
Sends a command to save parameters
4
Param Recall
Sends a command to reset parameters
5
Default Init
Sends a command to initialize parameters to their defaults
6
Clr Warnings
Sends a command to clear warnings in the RGU
7
Reset Cmd
Sends a command to reset the RGU
8
Clr Flt Que
Sends a command to clear the fault queue
9
Clr Wrn Que
Sends a command to clear the warning queue
10
Disable Cmd
Sends a command to Disable the RGU control
11
Run Startup
Sends a command to reset the RGU and to initiate the startup sequence
12-15 Not Used
33
Host Status Word 1
[Host Status 1]
This parameter indicates a number of conditions
that the RGU is experiencing.
A condition is indicated by the bit being set to 1.
For example, the word, 0000 0011 0100 0000,
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0000 0000 0000 0000
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Related Parameters
P32, P34, P35
indicates that the DC bus is at voltage, the DSP
processor is ready, and control is ready.
Bit
Description
0
Hard Fault
Indicates that a hard fault has occurred.
1
Warning Flt
Indicates that a warning fault has occurred.
2
Clr Faults
Indicates that clear fault command(s) are pending.
3
Clr Warnings
Indicates that clear warning command(s) are pending.
4
BCR Relay
Indicates that the bus control relay is closed.
5
Bus 1/2 Up
Indicates that the DC bus is at half of the rated voltage.
6
Bus Up
Indicates that the DC bus is at rated voltage.
7
Enable
Indicates that the RGU control is enabled.
8
DSP Ready
Indicates that the DSP processor is ready.
9
Ctrl Ready
Indicates that the RGU control is ready.
10-14 Not Used
15
Ctrl Running
The RGU control is active.
Bit
8
Bit
9
Bit
10
Bit
11
Bit
12
Bit
13
Bit
14
Bit
15
Bit
0
Bit
1
Bit
2
Bit
3
Bit
4
Bit
5
Bit
6
Bit
7
Bit
8
Bit
9
Bit
10
Bit
11
Bit
12
Bit
13
Bit
14
Bit
15
Bit
0
Bit
1
Bit
2
Bit
3
Bit
4
Bit
5
Bit
6
Bit
7
