Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) - Manual (Page 205)

Publication 2364F-5.01– October 2003
Programming Parameters D-61
326
Trend 3 Select
[Trend Select]
This parameter commands the RGU to enable,
disable, or force trigger Trend 3.
After the RGU processes the command, the value
resets to 3 (No Command).
Parameter Type Sink (Read/Write)
Display Units None
Drive Units Display Units * 1
Factory Default 3 (No Command)
Minimum Value 0
Maximum Value 3
Related Parameters P317 to P328 (See also P298)
Value Description
0 DisableCommands the RGU to disable Trend 3.
1 EnableCommands the RGU to enable Trend 3.
2 Force TrigCommands the RGU to force trigger Trend 3. The trending value (prescribed by P317) will be sent to Trend 3 Output Indirect (P328).
3 No CommandIndicates that no command is issued at this time.
327
Trend 3 Status
[Trend Status]
This parameter displays the status of Trend 3.
Parameter Type Sink (Read Only)
Display Units None
Drive Units Display Units * 1
Factory Default 1 (Unprogrammed)
Minimum Value 0
Maximum Value 4
Related Parameters P317 to P328 (See also P298)
Value Description
0 UnprogrammedTrend 3 is not programmed.
1 StoppedThe trending operation is stopped (trend X and trend Y values are not being evaluated).
2 RunningThe trending operation is running (trend X and trend Y values are being evaluated).
3 TriggeredThe trending operation between trend X and trend Y is true. The trending value (determined by P317) will be output through P328.
4 Forced TrigTrend 3 is triggered due to a ‘Force Trig’ command from the Trend 3 Select (P326 = 0). The trending value is output.
328
Trend 3 Output Indirect
[Trend Out Ind]
This parameter prescribes the destination of the
trend parameter value (listed in P317). The
trending operation (X [operator] Y) must be
evaluated as true for P328 to output the value
from the trend source in P317.
Parameter Type Sink (Read/Write)
Display Units Parameter Number
Drive Units Display Units * 1
Factory Default 0 (no selection)
Minimum Value 0
Maximum Value Maximum Defined Parameter Number
Related Parameters P317 to P327 (See also P298)
329
Trend 4 Input Indirect
[Trend In Ind]
This parameter designates the parameter to be
output when Trend 4 is triggered.
The source parameter defined here is passed to
the output (P328) when the trending operation is
evaluated as true.
Parameter Type Sink (Read/Write)
Display Units Parameter Number
Drive Units Display Units * 1
Factory Default 0 (no selection)
Minimum Value 0
Maximum Value Maximum Defined Parameter Number
Related Parameters P330 to 340 (See also P298)
330
Trend 4 Operand Indirect X
[Trend X Ind]
This parameter designates a source parameter to
be analyzed in the Trend 4 evaluation. The
source value is masked with the trend Y value
(P332 or P333).
Parameter Type Sink (Read/Write)
Display Units Parameter Number
Drive Units Display Units * 1
Factory Default 0 (disabled, P331 enabled)
Minimum Value 0
Maximum Value Maximum Defined Parameter Number
Related Parameters P329 to 340 (See also P298)
P331 (Trend 4 X Value) is used as the trend X
operand when this parameter is zero (default).
