Chapter
12
Setting Up Trending
Trending is a diagnostic tool that you can use to capture and retain an
input parameter data value until a trigger condition occurs. The RGU
has the capacity to setup and monitor up to 4 parameters, Trend 1
through Trend 4. With trending, you program the:
• parameter to sample
• trigger condition
• sampling rate
• quantity of samples to be taken after the trigger occurs
• whether trending is to occur one time or continuously
Parameters used by trending are shown in the table below.
Table 12.1 Trending Parameters
Description
Trend 1 Parameter
Number
Trend 2 Parameter
Number
Trend 3 Parameter
Number
Trend 4 Parameter
Number
source 293 305 317 329
variable X source 294 306 318 330
variable X constant value 295 307 319 331
variable Y source 296 308 320 332
variable Y constant value 297 309 321 333
operator (comparison type) 298 310 322 334
sampling rate 299 311 323 335
quantity of post-trigger samples 300 312 324 336
mode (one-shot or continuous operation) 301 313 325 337
select 302 314 326 338
status 303 315 327 339
output 304 316 328 340
