Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 104

Publication 2364F-5.01– October 2003
9-12
Adjusting Voltage and Current Regulation Parameters
1.
2.
3.
4.
5. Set P105 to the desired negative I
d
current limit between -40 and
0%.
6. Refer to P93 for the final voltage loop I
d
command between -60
and 60%.
If you want the I
d
mode select to be:
Then set P103 to:
Zero (factory default)
0
A constant value
1
From an auxiliary Id
2
The sum of a constant value and an auxiliary Id
3
If P103 is set to:
Then:
1 or 3
Set P102 to the desired I
d
current command between -
40% and 60%. A value of zero is default and should be
used for most applications.
If P103 is set to:
Then:
2 or 3
Set P101 to the desired auxiliary I
d
current command
between -40 and 60%.
If P103 is set to:
Then:
0
I
d
parameter (P93) will be zero.
