Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 186

Publication 2364F-5.01– October 2003
D-42
Programming Parameters
199
Current Loop Damping
[DSP Damping]
This parameter defines the damping used in the
current loop.
Parameter Type
Sink (Read/Write)
Display Units
%
Drive Units
Display Units * 1
Factory Default
100
Minimum Value
50
Maximum Value
200
Related Parameters
P198
200
Iq Reference Rate Limit
[Iq Change Rate]
This parameter defines the rate limit for the Iq
reference. This value is used by the current limiter
to prevent the Iq Reference (P96) from changing
too rapidly.
Parameter Type
Sink (Read/Write)
Display Units
% of P11
Drive Units
Display Units * 1
Factory Default
33.33
Minimum Value
2.44
Maximum Value
366.21
Related Parameters
P198
For example, a 575V AC M-code RGU, bydefault,
would not allow the Iq reference to change more than
200A (33.33% of 602A (P11)).
201
Per Unit Internal Capacitance Charge Rate
[Int Charge Rate]
This parameter indicates the charge rate of the
RGU internal capacitance.
To determine the rate, divide P16 (Nominal DC
Bus Voltage) by this value.
Parameter Type
Source (Read Only)
Display Units
msec
Drive Units
Display Units * 1
Factory Default
27
Minimum Value
0.00
Maximum Value
1000
Related Parameters
P202
202
Per Unit System Capacitance Charge Rate
[Sys Charge Rate]
This parameter indicates approximate charge rate
for the system capacitance.
To determine the rate, divide P16 (Nominal DC
Bus Voltage) by this value.
Parameter Type
Source (Read Only)
Display Units
msec
Drive Units
Display Units * 1
Factory Default
32
Minimum Value
0.00
Maximum Value
1000
Related Parameters
P201
203
External Capacitance
[Ext Capacitance]
This parameter specifies the estimated sum
capacitace of the all the AC units connected to the
DC bus. This value is used to calculate the
proportional and integral gains in the PI regulator
(P118 and P119).
Parameter Type
Sink (Read/Write)
Display Units
uF/10
Drive Units
Display Units * 1
Factory Default
9600
Minimum Value
10
Maximum Value
65000
Related Parameters
P202, P204
See Chapter/(Appendix)
8, (B)
See Appendix B for a listing of inverter capacitor
bank values.
