Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 166

Publication 2364F-5.01– October 2003
D-22
Programming Parameters
101
Auxiliary Id Command
[Aux Id Command]
This parameter specifies a value which can be
used to add to the value of the Id Current
Command (P102), or can be used as the source
sent directly to the Id limiter.
Parameter Type
Sink (Read/Write)
Display Units
% of P11
Drive Units
Display Units * 5120/100
Factory Default
0.0
Minimum Value
-40.0
Maximum Value
60.0
Related Parameters
P93, P102, P103
This parameter is used when ‘Aux Id Cmd’ or
‘Id Cmd + Aux’ is selected in the Id Mode Select
(P103 = 2 or 3).
102
Id Current Command
[Id Command]
This parameter specifies the Id current command
which can be passed to the Id limiter.
This parameter is used when ‘Id Command’ or ‘Id
Cmd + Aux’ is selected in the Id Mode Select
(P103 = 1 or 3).
Parameter Type
Sink (Read/Write)
Display Units
% of P11
Drive Units
Display Units * 5120/100
Factory Default
0.0
Minimum Value
-40.0
Maximum Value
60.0
Related Parameters
P93, P101, P103
