Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 149

Publication 2364F-5.01– October 2003
Programming Parameters
D-5
11
Rated AC Line Current
[Rated AC Current]
This parameter stores the rated input line current
of the RGU.
Parameter Type
Source (Read/Write)
Display Units
Amp
Drive Units
Display Units * 10
Factory Default
See below
Minimum Value
See below
Maximum Value
See below
Related Parameters
P4, P96, P100, P106
J-code RGUs
K-code RGUs
L-code RGUs
M-code RGUs
N-Code RGUs
Factory Default
76.9
Factory Default
181.8
Factory Default
330.0 (286.0*) Factory Default
678.0 (602.0*) Factory Default 906.0 (802.0*)
Minimum Value
43.4
Minimum Value
93.6
Minimum Value
200.3
Minimum Value
421.4
Minimum Value 561.5
Maximum Value 84.6
Maximum Value 200.0
Maximum Value 363.4
Maximum Value 746.2
Maximum Value 996.6
* Value applies to units with 575V AC inputs
12
AC Line Reactor Inductance
[Line Inductance]
This parameter lists the total inductance of the AC
line reactors (CH1-3) in standalone RGU
configurations. Check the labels on the AC
reactors to verify value.
Parameter Type
Sink (Read Only)
Display Units
uH
Drive Units
Display Units * 1
Factory Default
See below
Minimum Value
0
Maximum Value
3000
Related Parameters
P4
J-code RGUs
K-code RGUs
L-code RGUs
M-code RGUs
N-Code RGUs
Factory
Default
1193 (380/460V)
1853 (575V)
Factory
Default
510 (380/460V)
832 (575V)
Factory
Default
317 (380/460V)
404 (575V)
Factory
Default
137 (380/460V)
191 (575V)
Factory
Default
102 (380/460V)
144 (575V)
13
Utility AC Line Frequency
[Utility AC Freq]
This parameter defines the input frequency of the
RGU. Set to 50 or 60Hz.
Parameter Type
Sink (Read/Write)
Display Units
Hz
Drive Units
Display Units * 1
Factory Default
60
Minimum Value
45
Maximum Value
65
Related Parameters
None
14
Measured AC Line Voltage
[Line Voltage]
This parameter measures the incoming voltage on
the AC line.
Parameter Type
Source (Read Only)
Display Units
Vrms
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
800
Related Parameters
P10, P15
15
AC Line Voltage Calibration
[Line Voltage Cal]
This parameter measures the voltage on the input
line. The RGU must be Disabled (not modulating)
when calibrating with this parameter.
Parameter Type
Sink (Read/Write)
Display Units
%
Drive Units
Display Units * 720/1000
Factory Default
0
Minimum Value
-3.1
Maximum Value
3.1
Related Parameters
P14
To calibrate the measured AC line voltage (P14),
adjust P15 until the value of P14 matches the
reading of the AC input voltage on an external
voltmeter.
