Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 201

Publication 2364F-5.01– October 2003
Programming Parameters
D-57
306
Trend 2 Operand Indirect X
[Trend X Ind]
This parameter designates a source parameter to
be analyzed in the Trend 1 evaluation. The
source value is masked with the trend Y value
(P308 or P309).
Parameter Type
Sink (Read/Write)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
0 (disabled, P307 enabled)
Minimum Value
0
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P305 to P316 (See also P298)
P307 (Trend 2 X Value) is used instead when this
parameter equals zero (default).
307
Trend 2 X Value
[Trend X Value]
This parameter defines a constant to be masked
with the trend Y value (P308 or P309).
To use this parameter, the trend X indirect (P306)
must equal zero.
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-32768
Maximum Value
32767
Related Parameters
P305 to P316 (See also P298)
308
Trend 2 Operand Indirect Y
[Trend Y Ind]
This parameter designates a source parameter to
be analyzed in the Trend 2 evaluation. The
source value masks the trend X value (P306 or
P307). P309 (Trend 2 Y Value) is used as the
trend Y operand when this parameter equals zero.
Parameter Type
Sink (Read/Write)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
0 (disabled, P309 enabled)
Minimum Value
0
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P305 to P316 (See also P298)
309
Trend 2 Y Value
[Trend Y Value]
This parameter defines a constant used to mask
the trend X value (P306 or P307).
To use this parameter, the trend Y indirect (P308)
must equal zero.
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-32768
Maximum Value
32767
Related Parameters
P305 to P316 (See also P298)
