Programming Parameters
D-65
407
Signal Processor 2 Input
[SigProc 2 Input]
This parameter indicates the parameter that is to
be processed through Signal Processor 2.
Parameter Type
Sink (Read/Write)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
0 (no selection)
Minimum Value
0
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P408 to P411 (See also P402)
408
Signal Processor 2 Output
[SigProc 2 Output]
This parameter specifies where the results of the
processed value should be placed.
Parameter Type
Source (Read Only)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P407 to P411
409
Signal Processor 2 Gain
[SigProc 2 Gain]
This parameter specifies the gain that should be
applied to the source value (indicated in P407).
Note that the offset is applied before the gain.
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
1.00
Minimum Value
-4.00
Maximum Value
4.00
Related Parameters
P407 to P411
410
Signal Processor 2 Offset
[SigProc 2 Offset]
This parameter specifies the offset to apply to the
source value (indicated in P407).
Note that the offset is applied before the gain.
Parameter Type
Source (Read Only)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-32768
Maximum Value
32767
Related Parameters
P407 to P411
411
Signal Processor 2 Cutoff Frequency
[SigProc 2 Cutoff]
This parameter specifies the cutoff frequency to
be used by the signal processor.
Parameter Type
Source (Read Only)
Display Units
R/S (rad/sec)
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
-32768
Maximum Value
32767
Related Parameters
P407 to P410
412
Signal Processor 3 Input
[SigProc 3 Input]
This parameter indicates the parameter that is to
be processed through Signal Processor 3.
Parameter Type
Sink (Read/Write)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
0 (no selection)
Minimum Value
0
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P413 to P416 (See also P402)
413
Signal Processor 3 Output
[SigProc 3 Output]
This parameter specifies where the results of the
processed value should be placed.
Parameter Type
Source (Read Only)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P412 to P416
