Programming Parameters
181
Fault Status 3 Report Mask
[Flt Report Mask 3]
This parameter selects the faults that can be
reported to P180.
1 - Report
0 - Suppress
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
1111 1111 1111 1111
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Related Parameters
P180, P181
Bit
Description
Bit
Description
0
Clock Loss
Reports when the oscillator clock is lost.
8*
DPRAM Error
Reports errors in the DPRAM.
1
Double Bus
Reports memory access errors.
9
No Vloop Tic
Reports when the voltage loop clock is lost.
2
Watchdog
Reports when the watchdog timer is expired.
10*
No Fast Task
Reports when high speed tasks are not executing.
3
En at Pwr Up
Reports when the RGU is Enabled at power up.
11*
No Bgnd Task
Reports when background tasks are not running.
4
Battery Low
Reports when the BRAM battery is low.
12*
Addr Bus Err
Reports address bus errors.
5*
TIO Loss
Reports when the primary clock is lost.
13*
Data Bus Err
Reports data bus errors.
6*
R2R Dup Addr
Reports when RGUs have an address conflict.
14
Line Low
Reports when the AC line voltage falls below P26.
7*
Lost Master
Reports when Master communication is lost.
15
Line High
Reports when the AC line voltage exceeds P27.
* These items cannot be changed to zero.
182
Fault/Warning Select Mask 3
[Fault/Warn Mask3]
This parameter determines whether conditions
should be reported as a warning (0) or handled as
a fault (1).
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0011 1101 1110 1000
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Related Parameters
P180, P181
Bit
Description
Bit
Description
0
Clock Loss
Selects response to a lost clock.
8*
DPRAM Error
Selects response to DPRAM errors.
1
Double Bus
Selects response to memory access errors.
9
No Vloop Tic
Selects response to voltage loop timer errors.
2
Watchdog
Selects response to watchdog timer expiration.
10*
No Fast Task
Selects response to fast task lockup.
3
En at Pwr Up
Selects response when RGU Enables at pwr up.
11*
No Bgnd Task
Selects response to background task lockup.
4
Battery Low
Selects response to low BRAM battery voltage.
12*
Addr Bus Err
Selects response to address bus errors.
5*
TIO Loss
Selects response to primary clock being lost.
13*
Data Bus Err
Selects response to data bus errors.
6*
R2R Dup Addr
Selects response to duplicate address errors.
14
Line Low
Selects response to low voltage in the AC line.
7*
Lost Master
Selects response to losing the Master.
15
Line High
Selects response to high voltage in the AC line.
* These items cannot be changed to zero.
