Setting Up Trending
12-9
Trending Status
The trending operation has five associated states (refer to Figure 12.1
for an illustration of the trending operation cycle.):
Figure 12.1
Trending Operation Cycle
1.
Number
This Operator:
Compares:
0
Unprogrammed
Trending is not operational.
1
Stopped
No data samples are being taken and output
contains the data samples that have been taken for
the previous trending.
2
Running
The trigger condition has not been reached and data
samples are being taken at the specified rate.
Output contains the data samples from the previous
trend.
3
Triggered
The trigger condition has occured and the post
samples are being taken.
4
Forced Triggered
The trigger condition was forced so that the post
samples could be taken.
For the status of Trend:
See:
1
P303
2
P315
3
P327
4
P339
Forced Trigger
Running
Triggered
Stopped
Last post sample
gathered and in
continuous mode
Last post sample
gathered and in
continuous mode
Trend Enabled
Last post sample gathered
and in one shot mode
Trend Select
set to 2.
Programmed trigger
condition is true
Last post sample
gathered and in one
shot mode
