Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 184

Publication 2364F-5.01– October 2003
D-40
Programming Parameters
185
Fault/Warning Select Mask 4
[Fault/Warn Mask4]
This parameter determines whether conditions
should be reported as a warning (0) or handled as
a fault (1).
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0000 0001 0111 1010
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Related Parameters
P183, P184
Bit
Description
0
I2t Warnings
Selects response to warnings detected by the I2t wire overload protect circuit.
1*
I2t Overload
Selects response to overload conditions detected by the I2t wire overload protect circuit.
2
H/S HighTemp
Selects response when the RGU heatsink temperature is high (P87).
3*
Reset Req’d
Selects response to reset required conditions (P32).
4
NTC Open
Selects response to NTC open condition.
5
NTC Short
Selects response to NTC short condition.
6*
MSTR Faulted
Selects response when the master RGU faults (see P20).
7
1 Phase Warn
Selects response when single phase condition has been detected (see P147).
8
1 Phase Err
Selects response when single phase condition has persisted beyond time limit (see P148).
9-15
Not Used
* These items cannot be changed to zero.
186-188
P186-P188 are for internal use only.
189
Auxiliary Relay Source
[Aux Relay Ind]
This parameter specifies the source to be used in
the logic operation shown in P191. This source
parameter will be masked with the value in P190
to determine if the auxiliary relay will change state.
Parameter Type
Sink (Read/Write)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
33 (Host Status Word 1)
Minimum Value
0 (disabled)
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P190, P191, P192
190
Auxiliary Relay Mask
[Aux Relay Mask]
This parameter defines the mask to be applied to
the value of the Auxiliary Relay Source parameter
(P189).
Press F3 to change the parameter display to
binary, hexadecimal, etc.
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
1
Minimum Value
0
Maximum Value
65535
Related Parameters
P189, P191, P192
Bit
8
Bit
9
Bit
10
Bit
11
Bit
12
Bit
13
Bit
14
Bit
15
Bit
0
Bit
1
Bit
2
Bit
3
Bit
4
Bit
5
Bit
6
Bit
7
