Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) User Manual
Page 196

Publication 2364F-5.01– October 2003
D-52
Programming Parameters
272
RGU-to-RGU Transmit Indirect 2
[R2R Xmit Ind 2]
This parameter directs the master status indicated
in P20 (Master Status) to the R2R network.
Parameter Type
Source (Read Only)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
20 (Master Status)
Minimum Value
1
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P5, P20, P267
273
RGU-to-RGU Receive 1, Indirect 1
[R2R Rcv1, Ind1]
This parameter directs the Iq Current Reference
(P96) from the master to P89 (Auxiliary Iq Current
Command).
Parameter Type
Source (Read Only)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
89 (Auxiliary Iq Current Command)
Minimum Value
1
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P5, P89, P268
274
RGU-to-RGU Receive 1, Indirect 2
[R2R Rcv1, Ind2]
This parameter receives the status from the
master RGU through the R2R network. This
master status (Enabled/Faulted) is directed to P20
(Master Status).
Parameter Type
Source (Read Only)
Display Units
Parameter Number
Drive Units
Display Units * 1
Factory Default
20 (Master Status)
Minimum Value
1
Maximum Value
Maximum Defined Parameter Number
Related Parameters
P5, P20, P268
275-280
P275-P280 are for internal use only.
281
Scratch Pad 1
[Scratch Pad 1]
This parameter can be used to store
miscellaneous positive values.
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
65535
282
Scratch Pad 2
[Scratch Pad 2]
This parameter can be used to store
miscellaneous positive values.
Parameter Type
Sink (Read/Write)
Display Units
None
Drive Units
Display Units * 1
Factory Default
0
Minimum Value
0
Maximum Value
65535
Master RGU
Slave RGU
P89
Auxiliary Iq
Current
Reference
P273
R2R
Receive 1,
Indirect 1
P271
R2R
Transmit
Indirect 1
P96
Iq
Reference
Master RGU
Slave RGU
P20
Master
Status
P274
R2R
Receive 1,
Indirect 2
P272
R2R
Transmit
Indirect 2
P20
Master
Status
