Rockwell Automation 2364F Regenerative DC Bus Supply Unit (RGU) - Manual (Page 179)

Publication 2364F-5.01– October 2003
Programming Parameters D-35
175
Fault Status 1 Report Mask
[Flt Report Mask 1]
This parameter selects the faults that can be
reported to P174.
1 - Report 0 - Suppress
Parameter Type Sink (Read/Write)
Display Units None
Drive Units Display Units * 1
Factory Default 1111 1111 1111 1111
Minimum Value 0000 0000 0000 0000
Maximum Value 1111 1111 1111 1111
Related Parameters P174, P176
Bit Description Bit Description
0* ROM Bad CRC Reports ROM errors. 8* R2R HW Error Reports errors in the RGU-to-RGU hardware.
1* RAM Error Reports RAM errors. 9 Control Volt Reports control voltage faults.
2* BatRAM Err Reports errors in the battery-backed RAM. 10* H/S Overtemp Reports when the heatsink is at overtemperature.
3* DSP Load Reports DSP loading faults. 11 Bus Low Reports when the DC bus falls below min voltage.
4* FPGA Load Reports FPGA loading faults. 12 Bus High Reports when the DC bus rises above max voltage.
5 Iq Foldback Reports Iq foldback faults. 13 BRAM Chksum Reports parity errors in the battery-backed RAM.
6* M1 Open Reports when the M1 contactor opens. 14* Prchrg Fail Reports when the precharge operation fails.
7 SCANport Err Reports SCANport errors. 15* DSP Timeout Reports when the DSP times out.
* These items cannot be changed to zero.
176
Fault/Warning Select Mask 1
[Fault/Warn Mask1]
This parameter determines whether conditions
should be reported as a warning (0) or handled as
a fault (1).
The factory default, for example, shows that a
Parameter Type Sink (Read/Write)
Display Units None
Drive Units Display Units * 1
Factory Default 1100 0101 0101 1111
Minimum Value 0000 0000 0000 0000
Maximum Value 1111 1111 1111 1111
Related Parameters P174, P176
heatsink overtemperature causes a fault
(bit 10 = 1) and a low bus voltage produces a
warning (bit 11 = 0).
Bit Description Bit Description
0* ROM Bad CRC Selects response to ROM error. 8* R2R HW Error Selects response to RGU-to-RGU hardware error.
1* RAM Error Selects response to RAM error. 9 Control Volt Selects response to a control voltage condition.
2* BatRAM Err Selects response battery-backed RAM error. 10* H/S Overtemp Selects response to heatsink overtemperature.
3* DSP Load Selects response to DSP loading condition. 11 Bus Low Selects response to low bus voltage (P28).
4* FPGA Load Selects response to an FPGA loading condition. 12 Bus High Selects response to high bus voltage (P29).
5 Iq Foldback Selects response to an Iq foldback error. 13 BRAM Chksum Selects response to parity error in BRAM.
6* M1 Open Selects response to the M1 contactor opening. 14* Prchrg Fail Selects response to precharge failure.
7 SCANport Err Selects response to SCANport errors. 15* DSP Timeout Selects response to a DSP timeout.
* These items cannot be changed to zero.
Bit
8
Bit
9
Bit
10 Bit
11 Bit
12 Bit
13 Bit
14 Bit
15 Bit
0
Bit
1
Bit
2
Bit
3
Bit
4
Bit
5
Bit
6
Bit
7
Bit
8
Bit
9
Bit
10 Bit
11 Bit
12 Bit
13 Bit
14 Bit
15 Bit
0
Bit
1
Bit
2
Bit
3
Bit
4
Bit
5
Bit
6
Bit
7
