Rockwell Automation 1756-DMF30 ControlLogix Drive Module User Manual
Page 61
Publication 1756-UM522B-EN-P - February 2003
Configuring the Drive Module
5-17
Configure the Drive Module’s Peer Communication (continued)
The value tab is useful for configuring the module as a Time Keeper
Check this box if the
module is to be the
Time Keeper
Click OK when the
configuration is as
desired
