What is the ControlLogix Drive Module?
This chapter describes the ControlLogix Drive module. It also
describes what you must know and do before using the Drive
module.
What is the ControlLogix
Drive Module?
The 1756-DM Drive Module is a single slot ControlLogix based
module for interface to Reliance Electric Distributed Power System
(DPS) drive equipment. Each drive module interfaces with an
individual Power Module Interface (PMI) chassis, performing velocity
and position and outer torque control.
Figure 1.1 SD3000 System Example
For information about:
See page:
What is the ControlLogix Drive Module?
Connecting the Drive Module to SynchLink
and Drive Comm
Using Module Identification and Status
Information
Preventing Electrostatic Discharge
Removal and Insertion Under Power
Chapter Summary and What’s Next
Motor with
resolver
DPS with PMI
Chassis
Drive Communication
ControlLogix Chassis
with Drive Module
