Rockwell Automation 1756-DMF30 ControlLogix Drive Module - Manual (Page 293)

Publication 1756-UM522B-EN-P - February 2003
1756-DMF30 Specific Information C-41
631 Real In15
Displays input word 15 of the controller communication format
in floating point format. Paired with parameter 630 [Integer
In15], which displays the same data in integer format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Non-Linkable, Read-Only, Floating Point
Communication
Logix Inputs
632 Integer Out00
Displays output word 00 of the controller communication
format in integer format. Paired with parameter 633 [Real
Out00], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
633 Real Out00
Displays output word 00 of the controller communication
format in floating point format. Paired with parameter 632
[Integer Out00], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
634 Integer Out01
Displays output word 01 of the controller communication
format in integer format. Paired with parameter 635 [Real
Out01], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
635 Real Out01
Displays output word 01 of the controller communication
format in floating point format. Paired with parameter 634
[Integer Out01], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
636 Integer Out02
Displays output word 02 of the controller communication
format in integer format. Paired with parameter 637 [Real
Out02], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
637 Real Out02
Displays output word 02 of the controller communication
format in floating point format. Paired with parameter 636
[Integer Out02], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
638 Integer Out03
Displays output word 03 of the controller communication
format in integer format. Paired with parameter 639 [Real
Out03], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
No. Name
Description Values
