Publication 1756-UM522B-EN-P - February 2003
1756-DMF30 Specific Information C-45
663 Real Out15
Displays output word 15 of the controller communication
format in floating point format. Paired with parameter 662
[Integer Out15], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
664 Lgx Comm Format
Indicates the Controller to Drive Module communication
format.
• A value of 18 indicates User-Defined
• A value of 32 indicates Custom User-Defined
Default:
Min:
Max:
Type:
File:
Group: 0
0
4294967296
Non-Linkable, Read-Only, 32-Bit Integer
Communication
Commands
1000 SL Node Cnfg
Set bits to configure the SynchLink node.
• Setting bit 0 configures the local node as the Time
Master.
• Setting bit 2 configures the node to synchronize with
the Time Master immediately (1-2S per node) on
power-up or recovery. If you do not set bit 2, the node
will stay in the fast mode, taking up to 36S per node to
synchronize on power-up or recovery.
Default: 0000 0000 000 00000 0000 0000 0000 0100
Options Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9
Bti 10
Bit 11
Bit 12
Bit 13
Bit 14
Bit 15
Bit 16
Bit 17
Bit 18
Bit 19
Bit 20
Bit 21
Bit 22
Bit 23
Bti 24
Bit 25
Bit 26
Bit 27
Bit 28
Bti 29
Bit 30
Bit 31 Time Keeper
Reserved
Sync Now
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
File:
Group: SynchLink
SynchLink Config
1001 SynchLink Rev
Indicates the current revision of the local SynchLink
Programmable Logic Firmware. Default:
Min:
Max:
Type:
File:
Group: 0.1
0.1
999.9
Non-Linkable, Read-Only, 16-Bit Integer
Monitor
Drive Data
No. Name
Description Values
