Publication 1756-UM522B-EN-P - February 2003
C-44 1756-DMF30 Specific Information
655 Real Out11
Displays output word 11 of the controller communication
format in floating point format. Paired with parameter 654
[Integer Out11], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
656 Integer Out12
Displays output word 12 of the controller communication
format in integer format. Paired with parameter 657 [Real
Out12], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
657 Real Out12
Displays output word 12 of the controller communication
format in floating point format. Paired with parameter 656
[Integer Out12], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
658 Integer Out13
Displays output word 13 of the controller communication
format in integer format. Paired with parameter 659 [Real
Out13], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
659 Real Out13
Displays output word 13 of the controller communication
format in floating point format. Paired with parameter 658
[Integer Out13], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
660 Integer Out14
Displays output word 14 of the controller communication
format in integer format. Paired with parameter 661 [Real
Out14], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
661 Real Out14
Displays output word 14 of the controller communication
format in floating point format. Paired with parameter 660
[Integer Out14], which displays the same data in integer
format. Default:
Min:
Max:
Type:
File:
Group: 0
-2200000000
2200000000
Linkable, Read-Write, Floating Point
Communication
Logix Outputs
662 Integer Out15
Displays output word 15 of the controller communication
format in integer format. Paired with parameter 663 [Real
Out15], which displays the same data in floating point format. Default:
Min:
Max:
Type:
File:
Group: 0
-2147483648
2147483648
Linkable, Read-Write, 32-Bit Integer
Communication
Logix Outputs
No. Name
Description Values
