Appendix C
User Parameter Values
C–4
No. Name Default Value No. Name Default Value
310 Data In A1 0 359 Pot Offset +0.000
311 Data In A2 0 360 Pot Scale +1.000
312 Data In B1 0 361 Milli Amp Input +0
313 Data In B2 0 362 Milli Amp In Offset +0.000 mA
314 Data In C1 0 363 Milli Amp In Scale +2.000
315 Data In C2 0 364 SP Analog Sel 1
316 Data In D1 0 365 Sp Analog In 0
317 Data In D2 0 366 Sp An1 Scale 1 (32767)
320 Data Out A1 0 367 Sp Analog Select 1
321 Data Out A2 0 368 Sp Analog2 In 0
322 Data Out B1 0 369 SP An2 Scale 1 (32767)
323 Data Out B2 0 370 Analog Output 1 0
324 Data Out C1 0 371 Analog Out 1 Offset +0.000 volt
325 Data Out C2 0 372 An Out 1 Scale +0.500
326 Data Out D1 0 373 An Out 2 Scale 0
327 Data Out D2 0 374 Analog Out 2 Offset +0.000
330 SP Port Enable Msk 0111 1111 375 An Out 2 Scale +0.500
331 SP Direction Mask 0111 1111 376 mA Output 0
332 SP Start Mask 0111 1111 377 mA Output Offset 0.000 mA
333 SP Jog Mask 0111 1111 378 Regen Power Lmt +0.500
334 SP Ref Mask 0111 1111 379 Pos Mtr Cur Lim 0
335 SP Clr Flt Mask 0111 1111 384 Select for Tst DAC2 8
336 SP Reset Drv Mask 0111 1111 385 Input Mode 1
337 SP Local Cntrl Mask 0111 1111 386 Input Status 0000 0000
340 SP Stop Owner 0000 0000 387 Stop Select 1 0
341 SP Dir. Owner 0000 0000 388 Stop Select 2 0
342 SP Start Owner 0000 0000 389 Accel Rate 1 10 sec.
343 SP Jog 1 Owner 0000 0000 390 Accel Rate 2 3
344 SP Jog 2 Owner 0000 0000 391 Decel Rate 1 5000
345 SP Ref Owner 0000 0000 392 Decel Rate 2 0000 0000 0000 0000
346 SP Local Owner 0000 0000 393 Mop Increment 0000 0000 0000 0000
347 SP Flux Owner 0000 0000 394 Mop Value 0000 0000 0000 0000
348 SP Trim Owner 0000 0000 395 Pulse PPR 0000 0000 0000 0000
349 SP Ramp Owner 0000 0000 396 Pulse Edge 0000 0000 0000 0000
350 SP Clr Fault Owner 0000 0000 397 Pulse Scale 1750
352 10 Volt In Filtr 0.0 r/s 398 Pulse Offset 0.0
353 Pot In Fltr 0.0 r/s 399 Pulse Value 0.0
354 mA In Filtr 0.0 r/s 404 SP Comm Retries 0.0
355 10 Volt Input 0 405 Fault Select 0000 0000 0111 1111
356 10 Volt Offset 0.00 Volt 406 Warning Select 0000 0000 0111 1111
357 10 Volt Scale +2.000 407 Fault Status 0000 0000 0000 0000
358 Pot Input 0 408 Warning Status 0000 0000 0000 0000
