CP Configurable Warning Status
[CP Warn Status]
Parameter Number
84
Parameter Type
Source
Display Units
Bits
Drive Units
None
Factory Default
0000 0000 0000 0000
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Enums:
VP Configurable Warning Status (bits)
[VP Warn Status]
Parameter Number
85
Parameter Type
Source
Display Units
Bits
Drive Units
None
Factory Default
0000 0000 0000 0000
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Enums:
This word parameter indicates conditions
detected by the current processor (CP) that
have been configured to report as a Drive
Warning condition. Each configuration bit
matches the bit definitions of parameters
82, 86 and 87. When a bit is set to “1” the
corresponding condition in the Drive is
true, otherwise it is false.
This word parameter indicates conditions
detected by the Velocity Processor (VP)
that have been configured to report as a
Drive warning condition. Each configura-
tion bit matches the bit definitions of
parameters 83, 88 and 89. When a bit is
set to “1”, the corresponding condition in
the Drive is true, otherwise it is false.
Bit
Condition
0
Bus Ridethrough Timeout
1
Bus Precharge Timeout
2
Bus Drop
3
Bus Undervoltage
4
Bus Drop Cycles > 5
5
Fast Flux Up Current < 50%
Bit
Condition
0
Encoder Feedback Loss
1
Inverter Overtemp Pending
2
Motor Overtemperature Tripped
3
Motor Overload Pending (I
2
T)
4
Motor Overload Trip (I
2
T)
5
Motor Stalled
6
External Fault
7
RMS Fault
8
Not Used
9
Parameter Limit
10
Math Limit
Bit
Condition
11
Dynamic Brake Resistor Overtemperature
12
Motor Contactor Failure
13
Inverter Overload Pending (IT)
14
Drive to Drive Communication Fault
15
Inverter Overload Foldback
CP Fault/Warning Configuration Select
[CP Fault Select]
Parameter Number
86
Parameter Type
Sink
Display Units
Bits
Drive Units
None
Factory Default
0000 0000 0010 0011
Minimum Value
0000 0000 0000 0000
Maximum Value
1111 1111 1111 1111
Enums:
This word parameter determines conditions
detected by the Current Processor (CP)
that will be reported as either a drive fault
or drive warning condition. Each configu-
ration bit matches the bit definitions of
parameters 82, 84 and 87. When a bit is
set to ”1”, the corresponding condition in
the Drive will be reported as a FAULT,
otherwise it will be reported as a
WARNING.
Bit
Condition
0
Bus Ridethrough Timeout
1
Bus Precharge Timeout
2
Bus Drop
3
Bus Undervoltage
4
Bus Drop Cycles > 5
5
Fast Flux Up Current < 50%
