Document Update
1336 FORCE AC Drive User Manual
This document provides new and updated material for the 1336 FORCE
Adjustable Frequency AC Drive User Manual, publication 1336
FORCE-5.12, dated September, 1998. Please place this document with
your manual for future reference.
HIM Upload/Download Errors
The following information describes the possible errors that can be encountered
during a HIM Upload/Download procedure.
HIM Upload/Download Errors
Motor Control Board (v6.xx)
The following changes should be noted if a v6.xx Motor Control Board is being
used.
Fault Name Error Displayed Probable Cause Action
HIM -> Drive ERROR 1 The HIM calculated a checksum for the file to be
downloaded, then checked the EEPROM checksum of the
download. The checksums did not match, indicating the file
stored in the HIM is invalid and the download was not
successful. Upload a valid, uncorrupted file from the source
drive and then repeat the download.
ERROR 2 The number of parameters in the HIM file is different than
the number of parameters in the drive file. The smaller of
the two numbers is the number of parameters downloaded.
The last downloaded parameter number is displayed. Verify that the correct file is being downloaded to
the correct drive, then press the Enter key.
Manually reprogram parameters with numbers
higher than the last number downloaded or whose
values were incorrect.
ERROR 3 The file in the HIM is for a different type of drive than the
drive to which it is connected (i.e. 1336 FORCE file to 1336
IMPACT drive). Downloads can only occur between like
drive types. None - Download not allowed.
ERROR 4 The value just transferred to the drive is an illegal value (out
of range, too high or too low) for the parameter. Record the parameter number displayed and then
press Enter to continue the download. Manually
reprogram all recorded parameters after the
download is complete.
ERROR 5 The download was attempted while the drive was running. Stop the drive and repeat the download attempt.
ERROR 6 The file in the HIM is for a different HP or voltage drive than
the drive to which it is connected (i.e. 1336 FORCE 10 HP
file to 1336 FORCE 15 HP drive). If the download is desired, press the Enter key. If
not desired, press the ESCape key to end the
download
Drive -> HIM ERROR 1 The HIM calculated a checksum as the file was uploaded
and compared it to the HIM file checksum stored after the
upload. The checksums did not match, indicating the
upload was not successful and the HIM file is now
corrupted. Repeat the Upload.
