Appendix B
CE Conformity
B–2
Filter Selection:
Filter Catalog
Number
Three-Phase
Volts
Used with . . .
Frame
Reference
1336-RFB-30-A
200-240V
1336T-A001 - A003
A
380-480V
1336T-B001 - B003
B
1336-RFB-27-B
200-240V
1336T-A007
B
380-480V
1336T-B007 - B015
B
1336-RFB-48-B
200-240V
1336T-A010 - A015
B
380-480V
1336T-B020 - B030
B
1336-RFB-80-C
200-240V
1336T-A020 - A030
C
380-480V
1336T-BX040 - BX060
C
1336-RFB-150-D
200-240V
1336T-A040 - A050
D
380-480V
1336T-B060 - B100
D
1336-RFB-180-D
200-240V
1336T-A060
D
380-480V
1336T-B125 - BX150
D
1336-RFB-340-E
200-240V
1336T-A075 - A125
E
380-480V
1336T-B150 - B250
E
1336-RFB-475-G
380-480V
1336T-BX250 - B350
G
1336-RFB-590-G
380-480V
1336T-B400 - B450
G
1336-RFB-670-G
380-480V
1336T-B500 - B600
G
Not Available
380-480V
1336T-B700 - B800
H
EMC Enclosure Kit Selection
Frame
Enclosure Kit Catalog Number
Frame
Reference
200-240V Rating
380-480V Rating
500-600V Rating
B
1336-AE4
1336-AE4
1336-AE4
C
1336-AE5
1336-AE5
1336-AE5
D
1336-AE6
1336-AE6
1336-AE6
E
1336-AE7
1336-AE7
1336-AE7
F–H
Not Available
RFI Filter Installation
!
ATTENTION: To prevent electrical shock, disconnect the
power source before installing or servicing.
Important: Refer to the instructions supplied with the filter for details.
The RFI filter must be connected between the incoming AC supply line
and the drive input terminals.
RFI Filter Leakage Current
The RFI filter may cause ground leakage currents. Therefore a solid
ground connection must be provided as shown in the electrical
configuration scheme shown on the following page.
Filter
