Chapter 6
Troubleshooting
6–3
Table 6.A
1336 FORCE Main Control Fault Descriptions
Fault # Fault Text Parameter #
13000
13001
13002
13003
13004
03008
03009
03010
03011
03012
03013
02014
12016
12017
12018
12019
14020
16021
16022
04024
03025
03026
12027
02028
03029
12032
12033
12034
12035
12036
12037
05048
02049
01050
01051
01052
01053
05054
02055
03057
03058
09059
02060
02061
06062
02063
CP EPROM Flt
CP Int RAM Flt
CP Ext RAM Flt
CP Stack RAM Flt
VP MBI Failure (Dual Port)
VP EPROM Flt
VP Int RAM Flt
VP Ext RAM Flt
VP Stack RAM Flt
CP MBI Failure
AP MBI Failure
Power EEPROM Flt
Bus Overvoltage
Transistor Desat
Ground Fault
IOC Fault
SW Malfunction
M/S Cable Loss
M/S Ena Timeout
AP Handshake Error
Absolute Overspd
Analog Spply Tol
Atune/Diag Fail
Inv Temperature
VP – SW Error
Ridethrough Time
Precharge Time
Bus Drop
Bus Undervolt
Bus Drop Cycles >5
Open Circuit
Vel FB Loss
Inv Overtemp Pnd
Mtr Temperature
Motor Overld Pnd
Motor Overld Trp
Motor Stalled
External Flt In
RMS Fault
Parameter Limit
Math Limit
DB Overtemp
AC Contactor
Inv Overld Pnd
Drv to Drv Error
Inverter Overload
Bit #
80
80
80
80
80
80
80
80
80
80
80
80
81
81
81
81
81
81
81
81
81
81
81
81
81
82
82
82
82
82
82
83
83
83
83
83
83
83
83
83
83
83
83
83
83
83
00
01
02
03
04
08
09
10
11
12
13
14
00
01
02
03
04
05
06
08
09
10
11
12
13
00
01
02
03
04
05
00
01
02
03
04
05
06
07
09
10
11
12
13
14
15
LED
CP, Red 1 blink
CP, Red 2 blink
CP, Red 3 blink
CP, Red 4 blink
CP, Red 5 blink
VP, Red 1 blink
VP, Red 2 blink
VP, Red 3 blink
VP, Red 4 blink
VP, Red 5 blink
VP, Red 6 blink
VP, Red Flashing
CP, Solid Red
CP, Solid Red
CP, Solid Red
CP, Solid Red
CP, Solid Red
CP, Solid Red
CP, Solid Red
VP, Solid Red
VP, Flashing Red
VP, Flashing Red
CP, VP, Flash Red
VP, Solid Red
VP, Solid Red
CP, Flashing Red
CP, Flashing Red
CP, Flashing Red
CP, Flashing Red
CP, Flashing Red
CP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Flashing Red
VP, Solid Red
VP, Flashing Red
VP, Flashing Red
VP Flashing Red
Fault Type
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Hard
Hard
Hard
Hard
Hard
Hard
Hard
Hard
Hard
Soft
Soft
Soft
Hard
Hard
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Soft
Hard
Soft
Soft
Soft
