background image

Rockwell Automation Publication 520COM-UM001A-EN-E - April 2013

97

Appendix

C

DeviceNet Objects

Appendix C presents information about the DeviceNet objects that can be
accessed using Explicit Messages. For information on the format of Explicit
Messages and example ladder logic programs, see

Chapter 6

,

Using Explicit

Messaging

.

Supported Data Types

Object

Class Code

Page

Object

Class Code

Page

Hex. Dec.

Hex. Dec.

Identity Object

0x01 1

98

PCCC Object

0x67 103

111

Assembly Object

0x04 4

100

DPI Device Object

0x92 146

114

Connection Object

0x05 5

101

DPI Parameter Object

0x93 147

117

Register Object

0x07 7

103

DPI Fault Object

0x97 151

123

Parameter Object

0x0F

15

106

DPI Diagnostic Object

0x99 153

125

Parameter Group Object

0x10 16

109

TIP

See the DeviceNet specification for more information about DeviceNet objects.
Information about the DeviceNet specification is available on the ODVA web
site (

http://www.odva.org

).

Data Type

Description

BOOL

8-bit value – low bit is true or false

BOOL[x]

Array of n bits

CONTAINER

32-bit parameter value - sign extended if necessary

DINT

32-bit signed integer

INT

16-bit signed integer

LWORD

64-bit unsigned integer

REAL

32-bit floating point

SHORT_STRING

Struct of: USINT length indicator (L); USINT[L] characters

SINT

8-bit signed integer

STRINGN

Struct of: UINT character length indicator (W); UINT length indicator (L); USINT[W x L] string data

STRING[x]

Array of n characters

STRUCT

Structure name only – no size in addition to elements

TCHAR

8 or 16-bit character

UDINT

32-bit unsigned integer

UINT

16-bit unsigned integer

USINT

8-bit unsigned integer
