Rockwell Automation Publication 520COM-UM001A-EN-E - April 2013
111
DeviceNet Objects
Appendix C
PCCC Object
Class Code
Services
Instances
Supports Instance 1.
Class Attribute
Not supported.
Instance Attributes
Not supported.
Message Structure for Execute_PCCC
Hexadecimal
Decimal
0x67
103
Implemented for:
Service Code
Class
Instance
Service Name
0x4B
Yes
Yes
Execute_PCCC
0x4C
No
Yes
Execute_DH+
0x4D
Yes
Yes
Execute_Local_PCCC
Request
Response
Name
Data Type
Description
Name
Data Type
Description
Length
USINT
Length of requestor ID
Length
USINT
Length of requestor ID
Vendor
UINT
Vendor number of requestor
Vendor
UINT
Vendor number of requestor
Serial Number
UDINT
ASA serial number of request
Serial Number
UDINT
ASA serial number of request
Other
Product Specific
Identifier of user, task, etc. on the requestor
Other
Product Specific
Identifier of user, task, etc. on the requestor
CMD
USINT
Command byte
CMD
USINT
Command byte
STS
USINT
0
STS
USINT
Status byte
TNSW
UINT
Transport word
TNSW
UINT
Transport word. Same value as the request.
FNC
USINT
Function code. Not used for all CMDs.
EXT_STS
USINT
Extended Status. Not used for all CMDs.
PCCC_params
Array of USINT
CMD/FNC specific parameters
PCCC_results
Array of USINT
CMD/FNC specific result data
