Rockwell Automation Publication 520COM-UM002A-EN-E - April 2013 23
Chapter
3
Configuring the Adapter
Chapter 3 provides instructions and information for setting the parameters to
configure the DeviceNet adapter.
For a list of parameters, see Appendix B , Adapter Parameters . For definitions of
terms in this chapter, see the Glossary .
Configuration Tools The adapter parameters can be configured using the drive keypad interface (see
page 23 ) or a PowerFlex 4-class HIM (Human Interface Module, see page 25 ).
RSLogix 5000/Logix Designer, Connected Components Workbench (version 3
or greater), and RSNetWorx for DeviceNet (version 21 or greater) can also be
used to access the adapter parameters.
Using the Drive Keypad
Interface to Access
Parameters The following is an example of basic integral keypad and display functions. This
example provides basic navigation instructions and illustrates how to program a
parameter.
Topic Page
Configuration Tools 23
Using the Drive Keypad Interface to Access Parameters 23
Using the PowerFlex 4-Class HIM to Access Parameters 25
Setting the Node Address 25
Setting the Data Rate 26
Setting the I/O Configuration 26
Using Master-Slave Hierarchy (Optional) 26
Selecting COS, Cyclic, or Polled I/O 28
Setting a Fault Action 29
Resetting the Adapter 30
Restoring Adapter Parameters to Factory Defaults 30
Viewing the Adapter Status Using Parameters 31
Updating the Adapter Firmware 31
IMPORTANT The DeviceNet adapter Device parameters can be accessed on the drive keypad
via the “N” (Network) group. Note that the parameters in the “N” group will
appear offset from the Device parameter numbers referenced in this manual by
1000 (decimal) on the LCD display.
