Rockwell Automation Publication 520COM-UM001A-EN-E - April 2013 107
DeviceNet Objects Appendix C
Class Attributes
Instance Attributes
Attribute ID Access Rule Name Data Type Description
1 Get Revision UINT 1
2 Get Max Instance UINT Number of parameters
8 Get Parameter Class Descriptor WORD 0 = False, 1 = True
Bit 0 = Supports parameter instances
Bit 1 = Supports full attributes
Bit 2 = Must do NVS save command
Bit 3 = Parameters are stored in NVS
9 Get Configuration Assembly Instance UINT 0
10 Get Native Language USINT 1 = English
2 = French
3 = Spanish
4 = Italian
5 = German
6 = Japanese
7 = Portuguese
8 = Chinese Simplified
9 = Reserved
10 = Reserved
11 = Korean
12 = Polish
13 = Reserved
14 = Turkish
15 = Czech
Attribute ID Access Rule Name Data Type Description
1 (1) Paramete
r Value (2) (3)
2 Get Link Path
Size USINT 0 = No link specified
n = Link specified
3 Get Link Path
(4)
4 Get Descriptor WORD 0 = False, 1 = True
Bit 1 = Supports ENUMs
Bit 2 = Supports scaling
Bit 3 = Supports scaling links
Bit 4 = Read only
Bit 5 = Monitor
Bit 6 = Extended precision scaling
5 Get Data Type USINT C3 = INT
C7 = UINT
D2 = WORD (16-bit)
6 Get Data Size USINT
(3)
7 Get Paramete
r Name
String SHORT_STRI
NG (3)
8 Get Units
String SHORT_STRI
NG
(3)
9 Get Help
String SHORT_STRI
NG 0
10 Get Minimum
Value (1) (3)
11 Get Maximum
Value
(1) (3)
