118 Rockwell Automation Publication 520COM-UM001A-EN-E - April 2013
Appendix C DeviceNet Objects
Instance Attribute
Attribute ID Access Rule Name Data Type Description
6 Get DSI Offline Read Full STRUCT of:
BOOL[32]
CONTAINER
CONTAINER
CONTAINER
STRING[16]
STRING[4]
UINT
UINT
UINT
UINT
UINT
UINT
UINT
USINT
USINT
UINT
UINT
CONTAINER
UINT
UNIT
UNIT
INT Descriptor
Offline Minimum value
Offline Maximum value
Offline Default value
Parameter name
Offline parameter units
Online minimum parameter instance
Online maximum parameter instance
Online default parameter instance
Multiplier parameter instance
Divisor parameter instance
Base parameter instance
Offset parameter instance
Formula number
Pad byte (always zero)
Help instance
Pad word (always a value of zero)
Parameter value
Multiplier
Divisor
Base
Offset
7 Get DSI Online Read Full STRUCT of:
BOOL[32]
CONTAINER
(1)
CONTAINER
CONTAINER
CONTAINER
UINT
UINT
STRING[4]
UINT
UINT
UINT
INT
USINT[3]
USINT
STRING[16]
Descriptor (see page 120 )
Parameter value
Minimum value
Maximum value
Default value
Next parameter
Previous parameter
Units (for example, Amps, Hz)
Multiplier
(2)
Divisor
(2)
Base
(2)
Offset (2)
Link (source of the value) (0 = no link)
Always zero (0)
Parameter name
8 Get DSI Descriptor BOOL[32] Descriptor (see page 120 )
9 Get/Set DSI Parameter Value Various Name of the component with support for Unicode.
10 Get/Set DSI RAM Parameter Value Various Parameter value in NVS. (3)
14 Get DSI Parameter Name STRING[16] Parameter name
18 Get International DSI Offline Parameter Text Struct of:
STRINGN
STRINGN International parameter name
International offline units
19 Get International DSI Online Parameter Text Struct of:
STRINGN
STRINGN International parameter name
International online units
