Rockwell Automation Publication 520COM-UM002A-EN-E - April 2013 25
Configuring the Adapter Chapter 3
Using the PowerFlex 4-Class
HIM to Access Parameters The PowerFlex 4-class HIM can be used to access parameters in the adapter (see
basic steps shown below). It is recommended that you read through the steps for
your HIM before performing the sequence. For additional HIM information,
refer to the HIM Quick Reference card, publication
22HIM-QR001 .
To display the
Host parameters, repeat steps 1 through 3 and select “PowerFlex
525” at step 3.
Setting the Node Address The value of
Device parameter 07 [Net Addr Cfg] determines the node address if
all the adapter DIP switches are in the OFF position (all 0’s). We recommend
that you do not use node address 63 because all new devices use it as the default
address. Address 63 is also used for Automatic Device Recovery (ADR).
1. Set the value of
Device parameter 07 [Net Addr Cfg] to a unique node
address.
Step Key(s) Example Display
1. Power up the drive. Then connect the HIM
to the DSI port of the drive. The Parameters
tab for the drive will be displayed.
2. Press Sel until the DSEL tab is selected.
3. Select DSI Device in the DSEL tab if it is not
already selected using the Up Arrow or
Down Arrow.
Press Enter to select DSI Device.
4. Press the Up Arrow or Down Arrow to scroll
to 25-COMM.
Press Enter to reload the HIM to browse
only the Communication Adapter (25-
COMM-D) parameters.
Parameters
Groups
Linear List
Changed Params
DIAG PARAM DSEL MEM SEL
Sel Device Select
DSI Devices
DIAG PARAM DSEL MEM SEL
and
DSI Devices
PowerFlex 525
25-COMM-D
Sel DSI Devices
PowerFlex 525
25-COMM-D
