Operation
3606 Rev 11/99
79
The attachments listed below are supplied with their own individual capacity
chart:
• 12’ Truss Boom
• 48, 60 & 72” Side Tilt Carriage
• 52 & 72” Swing Carriage
Hydraulically actuated attachments also have a maximum hydraulic
pressure rating. Ensure that the maximum rated hydraulic pressure of the
attachment is equal to or slightly greater than 3,500 psi (241,2 bar), which is
the maximum pressure of the vehicles auxiliary hydraulics at the quick
disconnect couplers.
1. Bring the vehicle to a complete stop using the service brakes.
2. Park the vehicle on level ground.
3. Place the travel select lever in (N) NEUTRAL and engage the park-
ing brake switch.
4. Lower the boom and ground the carriage.
5. Turn the ignition key to the OFF position and remove the key.
Shut-Off
WARNING
To prevent personal injury or death, be certain to lower the boom, shut
off the engine and engage the parking brake switch prior to exiting the
vehicle.
