Page 65
Operation
3606 Rev 11/99
63
Maximum Fork Sweep
(Figure 41)
Figure 41
CAUTION
Allow for adequate clearance between the attachment and other
objects when turning.
The attachment extends beyond the end of the vehicle. The operator
must be aware of the maximum sweep of the attachment when turning,
in order to avoid hitting personnel, and other objects in the area.
OS0321
Vehicle
Turning
Radius
Maximum
Fork
Sweep
Center Point of
Turning Radius
Operation
3606 Rev 11/99
63
Maximum Fork Sweep
(Figure 41)
Figure 41
CAUTION
Allow for adequate clearance between the attachment and other
objects when turning.
The attachment extends beyond the end of the vehicle. The operator
must be aware of the maximum sweep of the attachment when turning,
in order to avoid hitting personnel, and other objects in the area.
OS0321
Vehicle
Turning
Radius
Maximum
Fork
Sweep
Center Point of
Turning Radius
