Warning, Operation – SkyTrak 3606 Operation Manual User Manual
Page 54
52
3606 Rev 11/99
Operation
To unlock the fuel cap:
1. Level the vehicle, ground the carriage, place the travel select lever
in (N) NEUTRAL, engage the parking brake switch and turn the
ignition switch to the OFF position. Remove the keys from the igni-
tion.
Figure 33
2. Insert the fuel key (included with the ignition keys) into the fuel cap
(Figure 33).
3. Turn the key 1/4 turn counterclockwise, then back. Remove the key.
4. Slowly unscrew the cap and wait for any “hissing” noise to stop.
THEN unscrew the cap all the way.
To lock the fuel cap:
1. Turn the cap clockwise until you hear three distinct “clicks”. The fuel
cap is now locked.
WARNING
REMOVE FUEL CAP SLOWLY. Fuel spray may cause injury.
Fuel can spray out on you if you open the cap too quickly.
OS0540
Fuel Key
Fuel Cap
52
3606 Rev 11/99
Operation
To unlock the fuel cap:
1. Level the vehicle, ground the carriage, place the travel select lever
in (N) NEUTRAL, engage the parking brake switch and turn the
ignition switch to the OFF position. Remove the keys from the igni-
tion.
Figure 33
2. Insert the fuel key (included with the ignition keys) into the fuel cap
(Figure 33).
3. Turn the key 1/4 turn counterclockwise, then back. Remove the key.
4. Slowly unscrew the cap and wait for any “hissing” noise to stop.
THEN unscrew the cap all the way.
To lock the fuel cap:
1. Turn the cap clockwise until you hear three distinct “clicks”. The fuel
cap is now locked.
WARNING
REMOVE FUEL CAP SLOWLY. Fuel spray may cause injury.
Fuel can spray out on you if you open the cap too quickly.
OS0540
Fuel Key
Fuel Cap
