58 3606 Rev 11/99
Operation
If steps 1 through 9 prove positive, the Stabil-TRAK system is functioning
properly and the vehicle can be returned to service. If any of these steps
indicate that the Stabil-TRAK system is not functioning properly, contact
your local Sky Trak Distributor immediately to repair the system.
Starting Travel
1. Enter the operator cab, fasten the seat belt, start the engine, apply
the service brake pedal and disengage the parking brake switch.
2. Rotate the twist grip of the range select lever to 1st gear.
3. Move the travel select lever to (F) FORWARD to travel in a forward
direction or to (R) REVERSE to travel backward.
4. Slowly remove your foot from the service brake pedal and press the
accelerator pedal to start travel.
IMPORTANT! Check for warning lights frequently during operation. Any
abnormal indication should be corrected as soon as practical.
Changing Travel Direction
1. Stop the vehicle by applying the service brakes.
2. Grasp the travel select lever, pull it toward the steering wheel then
move the lever up or down to the opposite direction;
(R) REVERSE or (F) FORWARD.
Shifting Gears
1. Rotate the twist grip of the gear select lever to the next desired
gear.
NOTE: Shifting to the next higher gear may be done while the vehicle is in
motion.
IMPORTANT! When downshifting, allow the engine speed to slow down
before shifting to the next lower gear.
Both vehicles equipped with Turbocharged engines have four speed
transmissions, however vehicles equipped with the Naturally Aspirated
Perkins engine have three speed transmissions. Shifting into the fourth
forward gear with the above descibed vehicle will have no effect.
