Operation
3606 Rev 11/99 69
Figure 45
The boom angle indicator, located on the left side of the outer boom,
indicates the angle of the boom and also corresponds with the angles
indicated on the capacity chart.
Figure 46
To accurately use the capacity chart, the operator must first determine three
important things:
1. Weight of the load being lifted.
2. Height of the structure where the load is to be placed.
3. Distance where the load will ultimately be placed in front of the front
tires.
A B
OS1710
Boom Extend Stripes
Intermediate
Boom
OS0240
Boom Angle Indicator Outer Boom
