Page 24
22
3606 Rev 11/99
Operation
Travel Select Lever
(Figure 9)
The travel select lever has three positions to select direction of travel:
F = FORWARD ...................................all the way UP
N = NEUTRAL ....................................CENTER position
R = REVERSE....................................all the way DOWN
Figure 9
To change travel selections, grasp the lever and pull it toward the steering
wheel, then UP or DOWN to the desired selection.
When the travel select lever is shifted to REVERSE, the back-up alarm will
automatically sound.
NOTE: The travel select lever must be in the (N) NEUTRAL position to per-
mit engine starting.
OS0340
Travel
Select
Lever
OS0130
22
3606 Rev 11/99
Operation
Travel Select Lever
(Figure 9)
The travel select lever has three positions to select direction of travel:
F = FORWARD ...................................all the way UP
N = NEUTRAL ....................................CENTER position
R = REVERSE....................................all the way DOWN
Figure 9
To change travel selections, grasp the lever and pull it toward the steering
wheel, then UP or DOWN to the desired selection.
When the travel select lever is shifted to REVERSE, the back-up alarm will
automatically sound.
NOTE: The travel select lever must be in the (N) NEUTRAL position to per-
mit engine starting.
OS0340
Travel
Select
Lever
OS0130
