Operation
3606 Rev 11/99
57
brake pedal and increase the engine RPM slightly if necessary just
enough to back the vehicle off the block, while keeping the service
brake pedal partially depressed so the Stabil-TRAK light remains
ON. The rear axle should remain locked while backing off the block
and the front left tire should remain off the ground.
5. While keeping the service brake pedal depressed, move the travel
select lever to the (N) NEUTRAL position and take your foot off the
service brake pedal. The rear axle should remain locked, the Stabil-
TRAK light should remain ON, and the front left tire should remain
off the ground.
6. With the travel select lever in the (N) NEUTRAL position, engage
the parking brake switch and move the travel select to the
(F) FORWARD position. The rear axle should remain locked, the
Stabil-TRAK light should remain ON, and the front left tire should
remain off the ground.
7. With the parking brake switch ON, move the travel select lever to
the (N) NEUTRAL position, and lower the boom to exactly 45°. Use
the frame sway control to tilt the vehicle no more than 5° to the left
and then no more than 5° to the right. The vehicle should sway
slowly to the left and then to the right. The Stabil-TRAK light should
remain ON, and the left front tire should remain off the ground. The
front left tire should not raise or lower when swaying. Leave the
vehicle swayed to the right 1° to 2°.
8. Depress the service brake pedal. Disengage the parking brake
switch and move the travel select lever to the (R) REVERSE posi-
tion. Release the service brake pedal to deactivate the Stabil-TRAK
system and the Stabil-TRAK light should go OFF. The left front tire
should return to the ground while the vehicle travels in reverse.
Depress the service brake pedal to stop the vehicle.
9. With the service brake pedal depressed, boom angle at exactly 45°,
move the range select lever to (3) third and the travel select lever to
(F) FORWARD. Release the service brake pedal to deactivate the
Stabil-TRAK system and the Stabil-TRAK light should go OFF.
Slowly drive the vehicle forward against the block to stop the vehicle
from moving forward. With the front left tire against the block, frame
sway the vehicle no more than 5° in both directions while checking
that the front tires remain on the ground. It is normal for the left front
tire to raise slightly when swaying to the left and for the front right
tire to raise slightly when swaying to the right, but the tires should
immediately lower when the frame sway function is stopped. The
tires should not come completely off the ground during this step.
Frame sway the vehicle back to 0°. Depress the service brake
pedal, shift the travel select lever to (N) NEUTRAL and lower the
boom.
