AT-S25 Management Software User’s Guide
61
The Port Configuration menu in Figure 16 is displayed.
Figure 16 Example of Port Configuration Menu
Note
The example Port Configuration window in the figure above is for a
10/100 Mbps twisted pair port. The window for a fiber optic port will
contain a subset of the parameters.
7. Enter or modify the parameters in the window as desired.
Changes to the parameters take effect immediately on the switch.
Table 2 lists the parameters used in the Port Configuration
window:
Table 2 Port Configuration Parameters
PARAMETER DESCRIPTION
1 - State
Sets the current state of the selected port or the first
port in the selected range.
Settings for this parameter are:
• Enable (default): The port forwards frames.
• Disable: The port will not forward frames.
2 - Broadcast
Filter
Sets the selected port to receive broadcast traffic.
Settings for this parameter are:
• Enable: The port discards all ingress broadcast frames.
• Disable (default): The port forwards all ingress
broadcast frames.
